Luer Lock Access Needle Free Check Valve with Female/Male Luer Lock, Clear Gamma Polycarbonate

Luer Lock Access Needle Free Check Valve with Female/Male Luer Lock, Clear Gamma Polycarbonate

Name: Luer Lock Access Needle Free Check Valve with Female/Male Luer Lock, Clear Gamma Polycarbonate
SKU: E-N-190050
Availability: OutOfStock

E-N-190050

Luer Lock Access Needle Free Check Valve with Female/Male Luer Lock, Clear Gamma Polycarbonate

E-N-190050

In Stock

Luer Lock Access Needle Free Check Valve with Female/Male Luer Lock, Clear Gamma Polycarbonate

Add To Wishlist

Quantity

Price

1 - 5

£0.00

6 - 10

£0.00

11 - 20

£0.00

21 - 50

£0.00

51 - 100

£0.00

101 - 200

£0.00

201 - 500

£0.00

501

£0.00

Looking to purchase a large quantity? Click here

Product Details

Product Code E-N-190050

Product Name Luer Lock Access Needle Free Check Valve with Female/Male Luer Lock, Clear Gamma Polycarbonate

Personal Details

Please enter a CompanyPlease enter a valid Company, the maximum length is 50 characters Company *

Please select a valid Title, the maximum length is 12 characters. Title *

Please enter a First NamePlease enter a valid First Name, the maximum length is 50 characters. First Name *

Please enter a Last NamePlease enter a valid Last Name, the maximum length is 50 characters. Last Name *

Contact Details

Please select a valid Contact Number, the maximum length is 30 charactersPlease enter a valid Contact Number consisting only of the following characters & spaces ( ) + 0 1 2 3 4 5 6 7 8 9 Contact Number *

Please enter a valid Email AddressPlease enter a valid Email AddressThe Email Address entered is already registered, please sign in with the Email Address or enter a different one Email Address *

Please enter a QuantityPlease enter a valid number between 10 and 999999 Quantity *

Opt in to receive updates regarding new products or promotions

Please confirm you are not a robot.

We have been unable to verify your identity, please confirm you are not a robot.

Product Information
Downloads
Sample request
Product Enquiry

Description Luer Lock Access Needle Free Check Valve with Female/Male Luer Lock, Clear Gamma Polycarbonate

Extended Description A Clear gamma grade Polycarbonate bodied luer lock access needle free check valve with female/male luer locks designed as a replacement for needle ports, they can be used for drug delivery/IV administration applications. These are used on a variety of balloon catheters such as endotracheal tubes, tracheostomy tubes, gastric feeding tubes and urethral catheters.

Ambient Temperature 0°C – 60°C (32°F – 140°F)

Mounting Style In-line

Connection 1 Female Luer Lock

Connection 2 Male Luer Lock

Recommended Filtration Not Applicable

Media Temperature 0°C – 60°C (32°F – 140°F)

Non-Wetted Materials Not Applicable

Wetted Materials Gamma Grade Polycarbonate, Silicone, Polypropylene

Cleanroom Manufactured No

Max. Inlet Pressure 1.38 bar (20 psi)

Cracking Pressure Valve Opened by Luer Connection

Item Weight 0.0020Kg (0.071oz)

ROHS Compliant Yes

CE Mark No

REACH Compliant Yes

Other Technical Data All materials are Gamma Resistant and Latex-free. Luer fittings are compatible with ANSI/HIMA MD70.1-83 & ISO 594. Valve stem and body will mate securely with all standard Luer syringes and Luer connectors. Product designedFor use in disposable applications.For further information please contact us on +44 (0)2392 266031.

Disclaimer: All information has been carefully collated and presented, however, Eoxshop cannot accept responsibility for incorrect or misprinted information

3D model (IGS)
